Description
- Measurement and recording of over 500 electric energy quality parameters acc. to en 50160,en 61000-4-30, en 61000-4-7 standards.
- Measuring class a – for 3 second aggregation. 10 minute and 2 hour aggregation – class S.
- operation in 3 or 4-wire, 3-phase, balanced or unbalanced power networks.
- analysis of current and voltage harmonics up to the 51 st for class i (acc. to en 61000-4-7).
- configurable archives of actual values and event recording.
- data archiving on an Sd card – memory up to 32 GB.
- e-mail messages in case of alarm occurs,
- web Server, Ftp Server.
- interfaces: rS-485 Modbus Slave, ethernet 100 Base-t (Modbus tcp Server)
- USB device & host.
- colour touch screen: lcd tFt 5.6”, 640 x 480 pixels.
- ip65 protection grade from the frontal side.
- Synchronization of rtc clock with the ntp time server.
