P30P-Transducer of 1-Phase Power Network Parameters with Data Record & Ethernet

P30P is a titransducer which was designed to measure 1-phase power network parameters. It can measure and record up to 16 parameters


The output signal is galvanically isolated from the input signal and the power supply.
P30P has programmable measurement and additional functions.

Transducer is available in 3 versions:

  • basic,
  • with SD/SDHC card,
  • with Ethernet and internal file system memory.
Categories: ,

Description

Features and functions:

  • Input:
    • analog (programmable): 1/5A
    • voltage: 100 or 230V
  • Output:
    • 1 x analog 0/4…20mA or 0…10V
    • 1 x relay, optionally changeable to 0/4…20mA or 0…10V analog output
    • 1 x additional relay, optionally changeable to 0…24V d.c. supply output
  • LCD 2 x 8 characters with LED backlight
  • Supply: 85..253 V a.c./d.c. or 20…40 V a.c./d.c., / 20…60 V d.c.
  • Conversion of measured values into an output signal on the base of the individual linear characteristic
  • 1 or 2 alarm relays with NO contact operating in 6 modes
  • Additional supplying output 24 V d.c 30 mA switched-on/switched-off (option).
  • Recording of input signals in internal file, on SD/SDHC card (option) or internal file system memory (option).
  • Interface RS-485 Modbus RTU.
  • RS-485 Master/Monitor mode – possibility to poll 1 device.
  • SD/SDHC support (option).
  • Interface Ethernet 10/100 BASE-T (opti on).
    • Protocol: Modbus TCP/IP, HTTP, FTP.
    • Services: www server, ft p server, client DHCP
  • Dimension: 45 x 120 x 100mm
